UV Light Air Shower Pass Box With Automatic Air Shower For Clean Room

UV Light Air Shower Pass Box With Automatic Air Shower For Clean Room

    • UV Light  Air Shower Pass Box With Automatic Air Shower For Clean Room
    • UV Light  Air Shower Pass Box With Automatic Air Shower For Clean Room
    • UV Light  Air Shower Pass Box With Automatic Air Shower For Clean Room
  • UV Light  Air Shower Pass Box With Automatic Air Shower For Clean Room

    পণ্যের বিবরণ:

    Place of Origin: Guangdong, China (Mainland)
    পরিচিতিমুলক নাম: Zhisheng
    সাক্ষ্যদান: ISO9001
    Model Number: ZS-FLP-1400

    প্রদান:

    Minimum Order Quantity: 1 set
    Packaging Details: plywood case
    Delivery Time: about 15 days upon receipt of deposit
    Supply Ability: 200sets per month
    এখন যোগাযোগ
    বিস্তারিত পণ্যের বর্ণনা
    Material: Cold rolled steel with powder coated Nozzels: stainless steel
    External size: W920xD660xH1400MM Color: Optional Color
    Construction-external: Stainless steel/cold plate paint Voltage: 220V


    UV Light Air Shower Pass Box With Automatic Air Shower For Clean Room



    Cleanroom pass boxes chambers are customized designed, rugged, made of high grade stainless steel.



    Controlling the ingress of particulate contamination into cleanrooms and other controlled environments is



    paramount in order to maintain the integrity of products and processess and protect the external



    environment from egress of contamination.



    They are customized according to the customer's different application requirements.


    The pass box with air shower has dust-cleaning function, so can be even more effectively stopping the open loop air circulation.



    Furthermore, the transported goods only enter the clean area after got air blown over, so the pollution can
    be minimized and dust particles will be effectively prevented from being carried out into the “dust-free room” by the transported goods.


    Features:



    External size: W920xD660xH1400MM



    Internal size: W600xD600xH600MM



    Material: Cold rolled steel with powder coated for outside casing, stainless steel for inside.



    Blower fan : 1400CMH.



    HEPA filter: 99.99% @ 0.3um  610x610x69mm 1 PCS



    Nozzles: 4 PCS



    Lock type: Magnetic interlocked.



    Windows: temper glass



    Handle: 2 sets



    Optional Features

    • HEPA filters
    • Fan filter units
    • Electric interlock system
    • Support brackets
    • Electro-polished finish for stainless steel pass box
    • Double wall construction (painted and stainless steel)
    • 304 Stainless Steel door frames with 1/4" thick clear tempered glass
    • Stainless steel/spring loaded door latch
    • UV light

    Application

    It mainly applied to the goods transimission between the clean and non-clean areas, preventing the outside dust particles from coming into the clean area due to air circulation.
    The possible pollution to clean room can be minimized, so the cleanliness of the clean room can be maintained.

    Standar size:


    Model ZS-FLP-1300 ZS-FLP-1400 ZS-FLP1750
    External dimensions (W x D x H) 820x560x1300 920x660x1400 920x660x1750
    Size for working area ((W x D x H) 500x500x600 600x600x600 600x600x600
    Material Cold rollled steel with powder coated for outside, stainless steel for inside
    Lock type mechanical interlock
    Windows Clear Acrylic sheet



    Model ZS-CC1 ZS-CC2 ZS-CC3
    External dimensions (W x D x H) 685x460x590 785x660x690 985x660x890
    Size for working area ((W x D x H) 500x400x500 600x600x600 800x800x600
    Material Cold rollled steel with powder coated for outside, stainless steel for base
    Lock type Mechanical interlock or Electronic interlock
    Windows Clear Acrylic sheet


    we can offer special size and requirement as per our clients.

    Drawing:

     UV Light  Air Shower Pass Box With Automatic Air Shower For Clean Room

    Testing in factory:

    All of equipment will be individually tested for safety and performance in accordance with international Standards before shipment. Each unit is shipped with a documentation outlining the tests undertaken and the units individual results for each unit.

    Testing before shipment:
    1. Appearance inspection
    2. Electrical safety tests
    3. Function testing

    Warranty:

    The warranty of our equipment is for 1 year, but excluding consumable parts and accessories.
    All equipment is shipped with a comprehensive use’s manual with testing report.
    Additional IO/OQ/GMP document is available upon request.
    Contact our sales representative for specific warranty details or document request.

    Why you choose ZHISHENG Company ?

    Professional service:

    Fast reply in 12 hours if we receive any inquiry or request from customer
    Familiar with equipment.

    Delivery time:
    Production period:15-30days
    • Shipping notice or insurance for you after the goods is shipped.

    After sales service:

    We respect your feed back after receive the goods.
